IPS Robot

MICRO light (DN 80 - 250)

Group Indoor Installation
Min. Order 1 piece
Terms of Payment all
Update Time 2018-02-27
Description

MICRO

light

  1. large range of application in pipes from DN 80 up to DN 150/3“ up to 6“ (inside diameter) without conversion work, optional extendable until DN 250/10“
  2. excellent flexibility in bends up to 90° in DN 100/4“ through rotating and swivel head
  3. pneumatic clamping unit permits use also in vertical pipes
  4. clamping unit separately controlable by cable remote control
  5. only very small access openings required
  6. convenient supply hose package of 30 m/98,40 ft
  7. extremely high cutting force through powerful air motor
  8. flexible operation through cable remote control
  9. very precise control of the cutter through joystick
  10. permanent monitoring of cutting operation due to integrated color camera in the cutting arm with air cleaning
  11. great mobility convenience through compact chassis
  12. damage prevention through automatic monitoring of internal pressure with signalling
  13. deep pipe insertion by fiberglass push rod possible
  14. variable cutting tools can be installed
  15. minimum downtimes in case of repair through operator-replaceable components or use of express service (see detailed description in the offer/order conditions)
  16. upgradeable to MICRO automatic at any time

MICRO

light

useable from DN 80 up to DN 150/3“ up to 6“ (inside diameter), up to DN 250/10“ with optional extensions

flexibility in bends 90° from DN 100/4“ (clay, no folds, or similar)
30 m/98,40 ft supply hose on dru
coupling elements for fiberglass push rod
400° rotating and approx. 90° swivel movement with stops
air-powered cutter motor
color camera with LED
camera cleaning with permanent air
splashproof according to IP 54
waterproof device with 0.8 bar nitrogen filling
permanent monitoring of internal pressure with signalling
cable remote control with joystick for rotation (sensitivity adjustable) and swivelling, controller for light, switch for cutting motor and bracing bladder control, 1 analogue BNC video output
3,5“ TFT LCD monitor, storage picture/video (JPEG/MPEG) with SD card, USB, date and time display on demand
outside diameter of cutter: 72 mm
overall dimensions: L 660 x W 550 x H 800 mm (L 26“ x W 22“ x H 31“)
weight: approx. 47 kg
compact cutter assembly on chassis with pneumatic rotary leadthrough
detachable individual components
box with job site tools, valve extension, set of replacement screws, 1 cutting tool carbidegranulate, nitrogen filling adapter, thread extension, ball bearings and fins for air motor, manual and spare parts overview
035 03 000Extension DN 200/8"035 04 000Extension DN 250/10"030 07 400Extension 5 m / 16 ft for remote control030 08 400Extension 50 m / 164 ft for remote control015 18 000Pipe eel 11 mm / 50 m / 164 ft015 01 133Toll extension030 06 900Inspection camera
